5 axis with 2heads machining Center

Working Types: do double ends Mortiser and tenoner, round tenon,square tenon,

Waist round tenon

Full numerical control adjustment,in the form of file storage

Double ends 5 axis with 2heads controller

It has the function of following the tool tip(open the processing file, and the equipment will adjust automatically

Using Windows system, the control software can be adjusted according to the actual usage

      Double end tenon processing tool, support G code online programming, left and right station independent, refuse to bump knife

Mechanical stroke

Left X axis stroke:750mm,  right:2000mm

Y axis stroke:

Z axis stroke:

A axis swivel head:181

C axis swivel head:continuous rotation

Processing range

Max Machining length:2000mm

Min Machining length:200mm (exclude tenoner’s working position)

Max Machining width:120mm

Max Machining thickness:80mm

Max machining size of left and right tool to workpiece center:350

Fixture that

fixture numbers: 2sets

Fixture size:100mm*40mm

Bin adjustment way: manual operation

Feeding way: 2 servo motors automatically

Receiving workpiece: Automatically( avoid scratch)

Left fisture is fixed ; right fixture can be adjusted the length)

　Tools that

Sawblade dia:230mm, D30mm

Sawblade end Fixture:ER20

Big Cutter shift dia :30mm

Motor turning speed:9000rpm, Power:5.5KW

Mill Cutter Fixture:ER25

Motor turining speed:18000rpm Power:2.2KW

Working Parameter

Maximum displacement velocity

X axis speed:50m/min

Y axis speed:50m/min

Z axis speed:50m/min

Input Power:25KW

Voltage:380V

Airpress: 6bar

Machine weight :about 4000kg

Machine accessory part

Precision Guiderail: Roust

Precision Pod : TBI

Server:Absolute server

Frequency:SZ Simphoenix

Pneumatic element : Airtac
